QWZ1000,QWZ1500,QWZ2500、QWZ4000,QWZ6000(The special order is available on the request)
Mainly used in building, coal, mining, light industry, chemical, cement, railway, port industry .They can also be used as source of vibration equipment.
mobile:+86 18737298575/18637236727
Product Application
Mainly used in building, coal, mining, light industry, chemical, cement, railway, port industry .They can also be used as source of vibration equipment.
Features
High Safety performance,even in explosive gas places.
Light weight, strong vibration force, stable amplitude, easy adjustment of vibrating force, machine shell made from cast iron ,wholly sealed.
Strong water resistance,no bearing can reduce routine maintenance and avoid bearing wear problems at high speed operating conditions.
Technical Parameter
| Product name | Type | air consumption |
Intake pipe diameter（mm） |
Vibration freq (Hz) |
Exciting force (N) |
Amplitude (mm) |
Total weight（kg） |
| PNEUMATIC EXTERNAL VIBRATORS | QWZ2500 | 1450 |
Φ16*Φ26 |
13000 | 2500 | 1.2 | 15 |
| QWZ4000 | 1630 |
Φ16*Φ26 |
15000 | 4000 | 1.6 | 15.8 | |
| QWZ1000 | 1100 | Φ12*Φ26 | 12000 | 1000 | 1.25 | 10 | |
| QWZ1500 | 1300 | Φ12*Φ26 | 15600 | 1500 | 2.0 | 11 | |
| QWZ6000 | 1830 | Φ16*Φ26 | 15000 | 6000 | 2.4 | 16.5 |
